The whole backpack is one box.
An IRL streaming backpack is really four things: a transmitter/encoder, the modems that get it online, a battery, and something to carry it in. A Lumbus Unit has the four modems built in and the bag in the price, so the rig on your belt is the Unit, your camera and your phone.
What you carry.
- The Unit: Niña (580 g, about 4 hours internal (50 wh)) or Pinta (about 2 hours internal, external battery supported), in the Lumbus belt pack.
- Your camera: any HDMI camera or a USB action camera on Niña; SDI or HDMI on Pinta. Cameras are not included.
- Your phone: the Lumbus Live app runs your studio and shows every connection, what it has used and what is left of your SIM allowance.
- SIMs: Lumbus SIMs, fitted when you order with a SIM allowance, or your own.
- Nothing else. Four mobile modems built in. No separate modem kit. The bag is in the price, and never a separate product.
The three Units.
Niña and Pinta ship with the Lumbus belt pack; Admiral, the 4K flagship, with the Lumbus backpack.
Lumbus Niña
The one to start with. Small enough to clip on.
- Camera
- Action cam, mirrorless or any camera with HDMI
- Battery
- About 4 hours on its own
- Comes with
- Belt pack, and 100 GB of Lumbus Connect to get you started
Or lock in the founding rate: 5% off
Technical detailsVideo, inputs and battery, in full
Compact 1080p60 transmitter/encoder — four mobile modems, HDMI and USB camera in
- Four mobile modems built in
- Up to 1080p60 · HDMI and USB camera in
- Belt pack included
- Up to 8 connections at once
- About 4 hours of battery
- Records locally · 64 GB card fitted
- 100 GB bonding allowance included
Lumbus Pinta
For professional cameras, with a touchscreen.
- Camera
- Broadcast and cinema cameras (SDI), or any camera with HDMI
- Battery
- About 2 hours on its own, longer with an external battery
- Comes with
- Belt pack, and 100 GB of Lumbus Connect to get you started
Technical detailsVideo, inputs and battery, in full
Professional 1080p60 transmitter/encoder — four mobile modems, SDI and HDMI in
- Four mobile modems built in
- Up to 1080p60 · SDI and HDMI in
- Belt pack included
- Up to 10 connections at once
- Touchscreen · four-channel embedded audio
- About 2 hours of battery · external battery supported
- Records locally · 64 GB card fitted
- 100 GB bonding allowance included
Lumbus Admiral
Our 4K flagship, for broadcast and several cameras at once.
- Cameras
- Up to four at once, or one in 4K, quoted with your project
- Battery
- More than 4 hours on its own, longer with an external battery
- Comes with
- Backpack, set up and supported by us
Technical detailsVideo, inputs and battery, in full
4K60 HDR flagship — up to eight mobile modems, four SDI and HDMI in
- Up to 4K60 · HDR · 10-bit 4:2:2
- Up to eight internal mobile modems
- 12G-SDI, three 3G-SDI and HDMI 2.0 in
- Up to 13 connections at once
- Four synchronised 1080p60 feeds, or one 4K60
- Intercom, return video and tally
- Backpack included
- Configured and supported by us
Niña and Pinta on your belt.
| Niña | Pinta | |
|---|---|---|
| Modems built in | Four | Four |
| Connections at once | 8 | 10 |
| Camera in | HDMI, USB | SDI, HDMI |
| Battery | About 4 hours internal (50 Wh) | About 2 hours internal, external battery supported |
| Weight | 580 g | Not on record yet |
| Bag | Belt pack, included | Belt pack, included |
| Price | $1,529, bought once | $2,149, bought once |
From the datasheets. A figure we do not hold is not a row.
When the signal goes.
On the move, the weak moment is in a crowd or between masts: upload collapses on one network while another is fine. A Unit on several networks at once, with Lumbus Connect using them as one stream, carries on over the connections that are still good.
And when every connection goes, Lumbus Studio keeps every platform connected and shows viewers Be right back instead of a frozen frame — then returns to Live by itself once your signal has held. Studio is optional and monthly, from $99 a month.
Packing for a stream day.
- 01Charge the Unit and your cameraNiña charges over USB-C; Pinta takes an external battery for a long day.
- 02Check your SIM allowance in the appThe app shows what is used and what is left, with a pause button.
- 03Point the Unit at your studio, onceYour Unit ships pre-addressed to your studio if you take one; it stays set.
- 04Go live from the appScenes, Force BRB and every connection, one-handed, mid-stream.
Technical detailsWeight, size, battery and operating range, from the datasheets
- Lumbus Niña
- 580 g · 175 × 95 × 32 mm · About 4 hours internal (50 Wh) · USB-C power in · 16 W maximum · −15 °C to 45 °C
- Lumbus Pinta
- About 2 hours internal · external battery supported · 9–17 V DC in · under 16 W · 105 × 168 × 44 mm · −20 °C to 50 °C
- The 100 GB in the box
- Every Niña and Pinta includes a 100 GB starter bonding allowance for Lumbus Connect, valid for three months — enough to set up, test and run your first bonded streams. Lumbus Connect is used when combining two or more connections, and on Niña for every stream. The SIM allowance is sold separately.
Questions
Is the bag included?
Yes, and it never has a price. Niña and Pinta ship with the Lumbus belt pack; Admiral ships with the Lumbus backpack. Neither is a separate product, an accessory line or an upsell at checkout.
How long does the battery last?
About 4 hours on Niña, about 2 on Pinta and more than 4 on Admiral. Pinta and Admiral can also run from an external battery.
Technical detailsThe full answer, in detail
About 4 hours on Niña, about 2 hours on Pinta and more than 4 hours on Admiral, on the internal battery. Pinta and Admiral also run from an external battery. Those are the datasheet figures; real time depends on what you plug in and how hard the modems work.
Do I need a separate modem kit?
No. Niña and Pinta already have four mobile modems built in.
Can I put a Lumbus SIM in my phone?
No. Lumbus SIMs are made for streaming hardware — they go in a Unit or another transmitter/encoder, not in a phone. If you stream from a phone today, keep the data plan you already pay for and add Lumbus Studio; Lumbus SIMs come later, with the Unit.
